VH7/9H3N -ELP -8K - STANDARD PARTS KIT
Includes parts lists for our Belliss VH 7/9 Series Compressor
Order Kit Part Number VH7 VH9H3N - ELP - 8K
As an authorised Gardner Denver distributor we only offer you the very best selection of genuine Belliss & Morcom products.
Parts can be purchased as individual items or as service kits, contact one of our experts to learn more about what we offer.
BELLISS VH 7/9 SERIES COMPRESSOR
Part Number | Part Name | Quantity |
|---|---|---|
2-01-570-02 | GASKET TOP COVER | 1 |
2-01-571-02 | GASKET 2ND CYLINDER | 1 |
2-01-572-03 | VITON 'O' RING BS4518 2493-57 | 1 |
2-01-643-04 | VITON 'O' RING BS4518 0596-24 | 4 |
PSB008-055 | CRANKCASE DOOR GASKET | 2 |
PSB008-056 | CRANKCASE GUIDE GASKET | 2 |
PSB006-018 | O RING INTERNAL DIA 164-5MM | 8 |
PSB006-013 | O RING 134.5 X 3.0 | 4 |
2-70-215-02 | VITON 'O' RING I/DIA 104.5MM | 1 |
2-70-216-02 | VITON 'O' RING I/DIA 94.5MM | 1 |
PSB032-014 | P.R. WRG PARTS | 4 |
PSB032-024 | P.R. PKG RINGS | 6 |
PSB032-012 | SCRAPER WEARING PARTS | 2 |
2-28-534-03 | 1ST PISTON RING | 2 |
2-28-534-04 | 1ST RIDER RING | 1 |
2-28-535-05 | 2ND PISTON RING | 3 |
2-28-535-06 | 2ND RIDER RING | 1 |
2-28-535-07 | 3RD PISTON RING | 6 |
PSB002-011 | PISTON NUT [M30 X 1.5] | 2 |
PSB025-001 | OIL SUC STRAINER | 1 |
PSB025-003 | OIL FILTER ELEMENT | 1 |
PSB025-006 | OIL FILTER ELEMENT 'O' RING | 1 |
ASB511-018 | AIR FILTER ELEMENT | 1 |
PSB008-057 | GASKET SCRAPER | 2 |
MB075-39 | STEEL COTTER PIN 5MM X 40MM | 4 |
2-01-570-05 | 2ND STAGE INLET GASKET | 2 |
2-01-571-04 | JOINT [2ND DEL FLG] | 1 |
2-04-304-02 | 3RD STAGE AIR IN/OUT JOINT | 2 |
MB030-06 | TAB WASHER 1/2" | 4 |
MB030-03 | LOCKING WASHER | 4 |
MB030-08 | TAB WASHER 5/8" | 4 |
2-72-582-08 | SEPERATOR JOINT | 1 |
2-72-582-07 | JOINT [A/COOLER] | 1 |
2-71-525-07 | 2ND STAGE INTERCOOLER JOINT | 1 |
PSB028-002 | POLYURETHANE WASHER | 7 |
Y30236 | O RING 69.5 X 3.0 | 1 |
PSB028-004 | SEAL [NEOPRENE] | 7 |
PSB014-012 | BOTTOM END SHELL | 2 |
PSB028-003 | DIAPHRAGM MZ100 | 7 |
